Ortur Laser Master 3 With Rotary Roller 20000mm/Min Off-line Control Laser Engraver and Cutter For Wood Metal Engraving Printer

Welcome to Ortur Outlet Store!

Note:

Model: Ortur Laser Master 3

Material: High precision CNC aluminum alloy frame

Power Adapter Output: 24V/2A

Optical power:  10W

Electric power: 40w

Spot size:  0.05*0.01mm

Engraving area:  400*400mm

Laser Wavelength:: 455±5nm

Engraving speed: 0-20000mm/min

Cutting thickness:  Cutting 20mm wood + 30mm acrylic one-time

Motherboard: OLM3 V2.0

Processor:  240MHz main frequency

Firmware type:  Support Ortur Laser 2.0 series firmware

Drive type:  TMC2209 high-division motor silent drive

Operating Temp: -20℃-50℃

Support offline:  WIFI, APP hotspot, SD card, USB data cable

Supported Operating Systems:

① LaserGRBL (free software) supports Windows XP, 7, 8, 10

② LightBurn (paid software, lightburnsoftware.com) supports Windows, Mac OS, Linux

Input Format: JPG, JPEG, PNG, BMP, SVG, etc

Installation time: 10-20 minutes (the body only needs 4 screws to be assembled)

After-sales service: One year warranty + Lifetime Service

Y-axis Rotary Roller  Features

Model: YRR

Material: Aluminum + Acrylic + Plastic

Size:129*184*81mm

Width Adjustment: 7 Gear Positions

Available Laser Engravers: Most kind of Desktop Laser Engravers

Package Contents: 1 x ORTUR Y-axis Engraving Module

7 Safety Protection Function:

1. Equipment maintenance reminder function: remind users to perform certain maintenance operations on the machine

2. Integrated system detection function: After the engraving machine fails, guide and help the user to perform the function detection of the engraving machine

3. Instruction reminder function: The system will notify the working status and potential faults of the OLM3 engraving machine system at the first time

4. Laser light emission detection and protection: check the working state of the laser and the light emission time to avoid fire accidents caused by long-term laser irradiation

5. Position offset detection and protection: If the machine is found to be offset after engraving, the system will immediately stop and alarm to avoid wrong engraving.

6. Machine inclination detection and protection: If it is found that the machine has a change in inclination after engraving, or even overturns, the system will stop immediately

7. Current and voltage detection and protection: If abnormal voltage fluctuation or short-circuit current overload is found, the system will shut down immediately to avoid permanent damage to the engraving machine

Main Function Definition

1.WIFI Aerial

2.Power Input

3.USB Port

4.Main Power Button(Status Light)

5.TF-Card

6.Upgrade Button(for Upgrading Firmware)

7.Reset Button

8.Input and Output Ports

9.Harness Interface

10.Y-axis Motor Interface

11.YRR transfer Switch

12.YRR motor Wire Port

APP Function

1.Graphic Editor

2.remote Control

3.Parameter Adjustment

4.Photo upload

5.Painting

6.Material Presets

7.Material library

8.Barcode generator

9.Firmware upgrade

10.Engraving preview

SD CARD SLOT Drag the NC file to the SD card, the machine starts working, and then you can turn off the computer or mobile phone without worrying about disconnecting, which is more convenient to print for a long time.
